Parallel kit motor interface 60R, 3 Nm EAMM-U-60-D32-60R-91 - Festo 1210434

Festo ✓ Original product Brand new

The parallel kit EAMM-U-60-D32-60R-91 from Festo places the motor parallel to the actuator and so shortens the overall length of the unit. Transmits up to 3 Nm of torque between motor and drive, plus clear matching via interface codes D32B (actuator) and 60R (motor). Genuine Festo accessory.

Net
€488.60
excl. VAT
Item FES-1210434
Manufacturer no. EAMM-U-60-D32-60R-91
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The parallel kit EAMM-U-60-D32-60R-91 places the motor parallel to the actuator and so shortens the overall length of the unit. Decisive for selection: motor interface 60R, 3 Nm, actuator D32B.

Benefits

  • Transmits up to 3 Nm of torque between motor and drive
  • Clear matching via interface codes D32B (actuator) and 60R (motor)
  • Ratio 1:1, motor speed is passed on unchanged
  • Speeds up to 6000 1/min permitted
  • 26.7 kgmm² mass moment of inertia, ready for the drive calculation
  • Frictional torque of 0.07 Nm for the torque budget

Application

Before ordering, check that the motor carries interface code 60R and the actuator matches D32B. The parallel layout of the EAMM-U-60-D32-60R-91 suits installations with little space behind the actuator. EAMM-U-60-D32-60R-91 can be installed in any mounting position at ambient temperatures of -10 to 60 °C.

Technical data

FeatureValue
TypeEAMM-U-60-D32-60R-91
Festo part number1210434
Size60
Mounting positionany
Gear ratio1:1
Max. rotational speed6000 1/min
LABS (PWIS) conformityVDMA24364 zone III
Storage temperature-25 to 60 °C
Relative air humidity0 to 95 %
Degree of protectionIP40
Ambient temperature-10 to 60 °C
Mass moment of inertia26.7 kgmm²
Frictional torque independent of load0.07 Nm
Transmittable torque3 Nm
Product weight1140 g
Interface code, actuatorD32B
Interface code, motor in60R
Note on materialsRoHS compliant
Weight1.2 kg
ManufacturerFesto
Hersteller-NrEAMM-U-60-D32-60R-91
EAN4052568414030
Zolltarifnummer84839089
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMM
Protection ratingIP40
Temperaturbereich-10-60 °C
Temperature (max.)60
