Parallel kit for motor mounting, 1 Nm, actuator D32B, motor 40P EAMM-U-50-D32-40P-48 - Festo 8164734
The EAMM-U-50-D32-40P-48 kit is intended for parallel motor mounting, with the motor lying next to the axis. It transmits up to 1 Nm of torque, the part is rated for up to 6000 1/min. Matches actuator interface D32B and motor interface 40P.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The EAMM-U-50-D32-40P-48 kit is intended for parallel motor mounting, with the motor lying next to the axis. It transmits up to 1 Nm of torque, the part is rated for up to 6000 1/min.
Key benefits
- Transmittable torque 1 Nm
- Speeds up to 6000 1/min
- Ratio 1:1, motor speed and torque reach the axis unchanged
- No-load driving torque only 0.01 Nm
- Mass moment of inertia 12.1 kgmm² for sizing the drive
- Degree of protection IP40, protected against solid objects from 1 mm
Application
Typical in machine building and handling, wherever a motor is connected to an electric axis. The values in the table are decisive for selection and apply to EAMM-U-50-D32-40P-48.
Technical data
| Type | EAMM-U-50-D32-40P-48 |
|---|---|
| Festo part no. | 8164734 |
| Size | 50 |
| Gear unit ratio | 1:1 |
| Transmittable torque | 1 Nm |
| Frictional torque independent of load | 0.01 Nm |
| Max. rotational speed | 6000 1/min |
| Mass moment of inertia | 12.1 kgmm² |
| Interface code, actuator | D32B |
| Interface code, motor in | 40P |
| Degree of protection | IP40 |
| Mounting position | Any |
| Ambient temperature | -10 to 60 °C |
| Storage temperature | -25 to 60 °C |
| Relative air humidity | 0 - 95 % |
| LABS (PWIS) conformity | VDMA 24364-zone III |
| Product weight | 479 g |
| Note on materials | RoHS compliant |
| Manufacturer | Festo |
| Hersteller-Nr | EAMM-U-50-D32-40P-48 |
| EAN | 4052568590635 |
| Zolltarifnummer | 84839089 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | EAMM |
| Protection rating | IP40 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
