Parallel kit motor interface 60R, 3 Nm EAMM-U-60-D32-60R-91-S1 - Festo 1210455
The Festo parallel kit EAMM-U-60-D32-60R-91-S1 places the motor parallel to the actuator and so shortens the overall length of the unit. Transmits up to 3 Nm of torque between motor and drive, plus clear matching via interface codes D32B (actuator) and 60R (motor). Genuine Festo accessory.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The parallel kit EAMM-U-60-D32-60R-91-S1 places the motor parallel to the actuator and so shortens the overall length of the unit. The key values: motor interface 60R, 3 Nm, actuator D32B.
Benefits
- Transmits up to 3 Nm of torque between motor and drive
- Clear matching via interface codes D32B (actuator) and 60R (motor)
- Ratio 1:1, motor speed is passed on unchanged
- Maximum rotational speed of 6000 1/min
- Mass moment of inertia of 26.7 kgmm² for motor sizing
- Frictional torque of 0.07 Nm for the torque budget
Application
Before ordering, check that the motor carries interface code 60R and the actuator matches D32B. Useful where axial space is limited, as with the EAMM-U-60-D32-60R-91-S1 in size 60. The mounting position of EAMM-U-60-D32-60R-91-S1 is freely selectable, ambient temperature range -10 to 60 °C.
Technical data
| Feature | Value |
|---|---|
| Type | EAMM-U-60-D32-60R-91-S1 |
| Festo part number | 1210455 |
| Size | 60 |
| Mounting position | any |
| Gear ratio | 1:1 |
| Max. rotational speed | 6000 1/min |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Storage temperature | -25 to 60 °C |
| Relative air humidity | 0 to 95 % |
| Degree of protection | IP65 |
| Ambient temperature | -10 to 60 °C |
| Mass moment of inertia | 26.7 kgmm² |
| Frictional torque independent of load | 0.07 Nm |
| Transmittable torque | 3 Nm |
| Product weight | 1170 g |
| Interface code, actuator | D32B |
| Interface code, motor in | 60R |
| Note on materials | RoHS compliant |
| Manufacturer | Festo |
| Hersteller-Nr | EAMM-U-60-D32-60R-91-S1 |
| EAN | 4052568414054 |
| Zolltarifnummer | 84839089 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | EAMM |
| Protection rating | IP65 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
