Parallel kit motor interface 28A, 0.05 Nm EAMM-U-30-V20-28A-44 - Festo 4767125
The parallel kit EAMM-U-30-V20-28A-44 from Festo places the motor parallel to the actuator and so shortens the overall length of the unit. Transmits up to 0.05 Nm of torque between motor and drive, plus clear matching via interface codes V20 (actuator) and 28A (motor). Genuine Festo accessory.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The parallel kit EAMM-U-30-V20-28A-44 places the motor parallel to the actuator and so shortens the overall length of the unit. At a glance: motor interface 28A, 0.05 Nm, actuator V20.
Benefits
- Transmits up to 0.05 Nm of torque between motor and drive
- Clear matching via interface codes V20 (actuator) and 28A (motor)
- Ratio 1:1 at a shaft centre distance of 44 mm
- Maximum rotational speed of 3000 1/min
- 2.11 kgmm² mass moment of inertia, ready for the drive calculation
- Frictional torque of 0.015 Nm for the torque budget
Application
Before ordering, check that the motor carries interface code 28A and the actuator matches V20. Useful where axial space is limited, as with the EAMM-U-30-V20-28A-44 in size 30. The mounting position of EAMM-U-30-V20-28A-44 is freely selectable, ambient temperature range 0 to 50 °C.
Technical data
| Feature | Value |
|---|---|
| Type | EAMM-U-30-V20-28A-44 |
| Festo part number | 4767125 |
| Size | 30 |
| Centre-to-centre distance | 44 mm |
| Mounting position | any |
| Gear ratio | 1:1 |
| Max. rotational speed | 3000 1/min |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Storage temperature | -20 to 60 °C |
| Relative air humidity | 0 to 95 % |
| Degree of protection | IP40 |
| Ambient temperature | 0 to 50 °C |
| Mass moment of inertia | 2.11 kgmm² |
| Frictional torque independent of load | 0.015 Nm |
| Transmittable torque | 0.05 Nm |
| Product weight | 97 g |
| Interface code, actuator | V20 |
| Interface code, motor in | 28A |
| Note on materials | RoHS compliant |
| Weight | 0.125 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EAMM-U-30-V20-28A-44 |
| EAN | 4052568292010 |
| Zolltarifnummer | 84839089 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | EAMM |
| Protection rating | IP40 |
| Temperaturbereich | 0-50 °C |
| Temperature (max.) | 50 |
