Axial kit motor interface 28A, 0.2 Nm EAMM-A-V20-28A - Festo 4505258
The axial kit EAMM-A-V20-28A from Festo connects the motor axially, in line with the drive axis, to the actuator. Transmittable torque of 0.2 Nm for sizing the drive train, plus fits actuators with code V20 and motors with code 28A. Maximum rotational speed of 10000 1/min. Genuine Festo accessory.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The axial kit EAMM-A-V20-28A connects the motor axially, in line with the drive axis, to the actuator. At a glance: motor interface 28A, 0.2 Nm, actuator V20.
Benefits
- Transmittable torque of 0.2 Nm for sizing the drive train
- Fits actuators with code V20 and motors with code 28A
- Maximum rotational speed of 10000 1/min
- Mass moment of inertia of 0.022 kgmm² for motor sizing
- Degree of protection IP40
- Ambient temperature -10 to 60 °C
Application
Before ordering, check that the motor carries interface code 28A and the actuator matches V20. The axial design keeps the EAMM-A-V20-28A unit slim in width. EAMM-A-V20-28A can be installed in any mounting position at ambient temperatures of -10 to 60 °C.
Technical data
| Feature | Value |
|---|---|
| Type | EAMM-A-V20-28A |
| Festo part number | 4505258 |
| Nominal length | 36.4 mm |
| Mounting position | any |
| Max. rotational speed | 10000 1/min |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Storage temperature | -25 to 60 °C |
| Relative air humidity | 0 to 95 % |
| Degree of protection | IP40 |
| Ambient temperature | -10 to 60 °C |
| Mass moment of inertia | 0.022 kgmm² |
| Transmittable torque | 0.2 Nm |
| Product weight | 27 g |
| Interface code, actuator | V20 |
| Interface code, motor in | 28A |
| Note on materials | RoHS compliant |
| Weight | 0.05 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EAMM-A-V20-28A |
| EAN | 4052568291853 |
| Zolltarifnummer | 84836080 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | EAMM |
| Protection rating | IP40 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
