Axial kit motor interface 80 PA/RA, 10 Nm EAMM-A-T46-80PA - Festo 8091047

Festo ✓ Original product Brand new

The axial kit EAMM-A-T46-80PA from Festo connects the motor axially, in line with the drive axis, to the actuator. Transmittable torque of 10 Nm for sizing the drive train, plus fits actuators with code T46 and motors with code 80 PA, 80RA. Speeds up to 8000 1/min permitted. Genuine Festo accessory.

Net
€113.25
excl. VAT
Item FES-8091047
Manufacturer no. EAMM-A-T46-80PA
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The axial kit EAMM-A-T46-80PA connects the motor axially, in line with the drive axis, to the actuator. Decisive for selection: motor interface 80 PA/RA, 10 Nm, actuator T46.

Benefits

  • Transmittable torque of 10 Nm for sizing the drive train
  • Fits actuators with code T46 and motors with code 80 PA, 80RA
  • Speeds up to 8000 1/min permitted
  • Mass moment of inertia of 7.65 kgmm² for motor sizing
  • Degree of protection IP40
  • Ambient temperature -10 to 60 °C

Application

Before ordering, check that the motor carries interface code 80 PA, 80RA and the actuator matches T46. The axial design keeps the EAMM-A-T46-80PA unit slim in width. EAMM-A-T46-80PA can be installed in any mounting position at ambient temperatures of -10 to 60 °C.

Technical data

FeatureValue
TypeEAMM-A-T46-80PA
Festo part number8091047
Nominal length68.5 mm
Mounting positionany
Max. rotational speed8000 1/min
LABS (PWIS) conformityVDMA24364-B2-L
Storage temperature-25 to 60 °C
Relative air humidity0 to 95 %
Degree of protectionIP40
Ambient temperature-10 to 60 °C
Mass moment of inertia7.65 kgmm²
Transmittable torque10 Nm
Product weight917 g
Interface code, actuatorT46
Interface code, motor in80 PA, 80RA
Note on materialsRoHS compliant
Weight0.95 kg
ManufacturerFesto
Hersteller-NrEAMM-A-T46-80PA
EAN4052568298890
Zolltarifnummer84836080
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMM
Protection ratingIP40
Temperaturbereich-10-60 °C
Temperature (max.)60
