Axial kit motor interface 80P, 10 Nm EAMM-A-T46-80P - Festo 4624170
The axial kit EAMM-A-T46-80P from Festo connects the motor axially, in line with the drive axis, to the actuator. Transmits up to 10 Nm of torque between motor and drive, plus clear matching via interface codes T46 (actuator) and 80P (motor). Speeds up to 8000 1/min permitted.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The axial kit EAMM-A-T46-80P connects the motor axially, in line with the drive axis, to the actuator. Decisive for selection: motor interface 80P, 10 Nm, actuator T46.
Benefits
- Transmits up to 10 Nm of torque between motor and drive
- Clear matching via interface codes T46 (actuator) and 80P (motor)
- Speeds up to 8000 1/min permitted
- 3.2 kgmm² mass moment of inertia, ready for the drive calculation
- Degree of protection IP40
- Suitable for ambient temperatures of -10 to 60 °C
Application
Before ordering, check that the motor carries interface code 80P and the actuator matches T46. The axial design keeps the EAMM-A-T46-80P unit slim in width. EAMM-A-T46-80P can be installed in any mounting position at ambient temperatures of -10 to 60 °C.
Technical data
| Feature | Value |
|---|---|
| Type | EAMM-A-T46-80P |
| Festo part number | 4624170 |
| Nominal length | 63.1 mm |
| Mounting position | any |
| Max. rotational speed | 8000 1/min |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Storage temperature | -25 to 60 °C |
| Relative air humidity | 0 to 95 % |
| Degree of protection | IP40 |
| Ambient temperature | -10 to 60 °C |
| Mass moment of inertia | 3.2 kgmm² |
| Transmittable torque | 10 Nm |
| Product weight | 840 g |
| Interface code, actuator | T46 |
| Interface code, motor in | 80P |
| Note on materials | RoHS compliant |
| Weight | 0.9 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EAMM-A-T46-80P |
| EAN | 4052568291921 |
| Zolltarifnummer | 84836080 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | EAMM |
| Protection rating | IP40 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
