Parallel kit motor interface 60 P/PA, 3.5 Nm EAMM-U-87-T46-60P-114 - Festo 4824069
The parallel kit EAMM-U-87-T46-60P-114 from Festo places the motor parallel to the actuator and so shortens the overall length of the unit. Transmittable torque of 3.5 Nm for sizing the drive train, plus clear matching via interface codes T46 (actuator) and 60 P, 60PA (motor).
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The parallel kit EAMM-U-87-T46-60P-114 places the motor parallel to the actuator and so shortens the overall length of the unit. The key values: motor interface 60 P/PA, 3.5 Nm, actuator T46.
Benefits
- Transmittable torque of 3.5 Nm for sizing the drive train
- Clear matching via interface codes T46 (actuator) and 60 P, 60PA (motor)
- Ratio 1:1 at a shaft centre distance of 114 mm
- Maximum rotational speed of 3000 1/min
- Mass moment of inertia of 41.2 kgmm² for motor sizing
- Frictional torque of 0.22 Nm for the torque budget
Application
Before ordering, check that the motor carries interface code 60 P, 60PA and the actuator matches T46. The parallel layout of the EAMM-U-87-T46-60P-114 suits installations with little space behind the actuator. The mounting position of EAMM-U-87-T46-60P-114 is freely selectable, ambient temperature range 0 to 50 °C.
Technical data
| Feature | Value |
|---|---|
| Type | EAMM-U-87-T46-60P-114 |
| Festo part number | 4824069 |
| Size | 87 |
| Centre-to-centre distance | 114 mm |
| Mounting position | any |
| Gear ratio | 1:1 |
| Max. rotational speed | 3000 1/min |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Storage temperature | -20 to 60 °C |
| Relative air humidity | 0 to 95 % |
| Degree of protection | IP40 |
| Ambient temperature | 0 to 50 °C |
| Mass moment of inertia | 41.2 kgmm² |
| Frictional torque independent of load | 0.22 Nm |
| Transmittable torque | 3.5 Nm |
| Product weight | 913 g |
| Interface code, actuator | T46 |
| Interface code, motor in | 60 P, 60PA |
| Note on materials | RoHS compliant |
| Weight | 0.95 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EAMM-U-87-T46-60P-114 |
| EAN | 4052568292072 |
| Zolltarifnummer | 84839089 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | EAMM |
| Protection rating | IP40 |
| Temperaturbereich | 0-50 °C |
| Temperature (max.) | 50 |
