Axial kit motor interface 57A, 6 Nm EAMM-A-T42-57A - Festo 4327034
The axial kit EAMM-A-T42-57A from Festo connects the motor axially, in line with the drive axis, to the actuator. Transmits up to 6 Nm of torque between motor and drive, plus clear matching via interface codes T42 (actuator) and 57A (motor). Maximum rotational speed of 8000 1/min.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The axial kit EAMM-A-T42-57A connects the motor axially, in line with the drive axis, to the actuator. At a glance: motor interface 57A, 6 Nm, actuator T42.
Benefits
- Transmits up to 6 Nm of torque between motor and drive
- Clear matching via interface codes T42 (actuator) and 57A (motor)
- Maximum rotational speed of 8000 1/min
- Mass moment of inertia of 3.2 kgmm² for motor sizing
- Degree of protection IP40
- Ambient temperature -10 to 60 °C
Application
Before ordering, check that the motor carries interface code 57A and the actuator matches T42. The axial design keeps the EAMM-A-T42-57A unit slim in width. EAMM-A-T42-57A can be installed in any mounting position at ambient temperatures of -10 to 60 °C.
Technical data
| Feature | Value |
|---|---|
| Type | EAMM-A-T42-57A |
| Festo part number | 4327034 |
| Nominal length | 43 mm |
| Mounting position | any |
| Max. rotational speed | 8000 1/min |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Storage temperature | -25 to 60 °C |
| Relative air humidity | 0 to 95 % |
| Degree of protection | IP40 |
| Ambient temperature | -10 to 60 °C |
| Mass moment of inertia | 3.2 kgmm² |
| Transmittable torque | 6 Nm |
| Product weight | 330 g |
| Interface code, actuator | T42 |
| Interface code, motor in | 57A |
| Note on materials | RoHS compliant |
| Weight | 0.36 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EAMM-A-T42-57A |
| EAN | 4052568291587 |
| Zolltarifnummer | 84836080 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | EAMM |
| Protection rating | IP40 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
