Axial kit for motor mounting, actuator P8-38A, motor 60R, 12.5 Nm EAMM-A-P8-38A-60R - Festo 8105916

Festo ✓ Original product Brand new

Connect motor and electric drive axially without designing your own adapter parts: the axial kit EAMM-A-P8-38A-60R fits actuator P8-38A and motor 60R and transmits up to 12.5 Nm. Speed up to 8000 1/min, degree of protection IP40. Mass moment of inertia 5.87 kgmm².

Net
€220.96
excl. VAT
Item FES-8105916
Manufacturer no. EAMM-A-P8-38A-60R
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo axial kit EAMM-A-P8-38A-60R connects a motor with interface code 60R coaxially to an electric drive with interface P8-38A. Transmittable torque is 12.5 Nm, maximum speed 8000 1/min.

Benefits

  • Transmittable torque 12.5 Nm between motor and drive
  • Speed up to 8000 1/min
  • Mass moment of inertia 5.87 kgmm² as input for drive sizing
  • Interfaces actuator P8-38A, motor 60R, coupling housing 38A
  • Degree of protection IP40, ambient temperature -10 to 60 °C

Applications

The EAMM-A-P8-38A-60R is used whenever a motor with interface code 60R has to be fitted to an electric drive with interface P8-38A. Typical applications are positioning axes in assembly, packaging and laboratory automation.

Technical data

Nominal length11.8 mm
Mounting positionAny
Max. rotational speed8000 1/min
LABS (PWIS) conformityVDMA24364-B2-L
Storage temperature-25 to 60 °C
Relative air humidity0 - 95%
Degree of protectionIP40
Ambient temperature-10 to 60 °C
Mass moment of inertia5.87 kgmm²
Transmittable torque12.5 Nm
Product weight145 g
Interface code, actuatorP8-38A
Interface code, motor in60R
Interface code, clutch housing38A
Note on materialsRoHS compliant
ManufacturerFesto
Hersteller-NrEAMM-A-P8-38A-60R
EAN4052568551049
Zolltarifnummer84836080
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMM
Protection ratingIP40
Temperaturbereich-10-60 °C
Temperature (max.)60
