Parallel kit motor interface 35 A, 23AB, 0.5 Nm EAMM-U-38-V25-35A-63 - Festo 8093286

Festo ✓ Original product Brand new

The Festo parallel kit EAMM-U-38-V25-35A-63 places the motor parallel to the actuator and so shortens the overall length of the unit. Transmits up to 0.5 Nm of torque between motor and drive, plus clear matching via interface codes V25 (actuator) and 35 A, 23AB (motor). Genuine Festo accessory.

Net
€190.09
excl. VAT
Item FES-8093286
Manufacturer no. EAMM-U-38-V25-35A-63
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The parallel kit EAMM-U-38-V25-35A-63 places the motor parallel to the actuator and so shortens the overall length of the unit. Decisive for selection: motor interface 35 A, 23AB, 0.5 Nm, actuator V25.

Benefits

  • Transmits up to 0.5 Nm of torque between motor and drive
  • Clear matching via interface codes V25 (actuator) and 35 A, 23AB (motor)
  • Ratio 1:1 at a shaft centre distance of 63 mm
  • Speeds up to 3600 1/min permitted
  • 4.35 kgmm² mass moment of inertia, ready for the drive calculation
  • Frictional torque of 0.05 Nm for the torque budget

Application

Before ordering, check that the motor carries interface code 35 A, 23AB and the actuator matches V25. The parallel layout of the EAMM-U-38-V25-35A-63 suits installations with little space behind the actuator. The mounting position of EAMM-U-38-V25-35A-63 is freely selectable, ambient temperature range 0 to 50 °C.

Technical data

FeatureValue
TypeEAMM-U-38-V25-35A-63
Festo part number8093286
Size38
Centre-to-centre distance63 mm
Mounting positionany
Gear ratio1:1
Max. rotational speed3600 1/min
LABS (PWIS) conformityVDMA24364 zone III
Storage temperature-20 to 60 °C
Relative air humidity0 to 95 %
Degree of protectionIP40
Ambient temperature0 to 50 °C
Mass moment of inertia4.35 kgmm²
Frictional torque independent of load0.05 Nm
Transmittable torque0.5 Nm
Product weight218 g
Interface code, actuatorV25
Interface code, motor in35 A, 23AB
Note on materialsRoHS compliant
Weight0.25 kg
ManufacturerFesto
Hersteller-NrEAMM-U-38-V25-35A-63
EAN4052568299125
Zolltarifnummer84839089
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMM
Protection ratingIP40
Temperaturbereich0-50 °C
Temperature (max.)50
