Coupling mounting Ø 20 / 22 mm, 60 Nm, size 56 EAMC-56-58-20-22 - Festo 8134825

Festo ✓ Original product Brand new

The coupling EAMC-56-58-20-22 connects shafts with 20 mm and 22 mm diameter and transmits up to 60 Nm at a maximum of 5500 1/min. Nominal length 58 mm, mass moment of inertia 128 kgmm². Motor mounting component for Festo electric drives.

Net
€121.99
excl. VAT
Item FES-8134825
Manufacturer no. EAMC-56-58-20-22
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

For motor mounting on electric drives, the Festo coupling EAMC-56-58-20-22 connects motor shaft and drive shaft. Mounting diameters of 20 mm and 22 mm, 60 Nm transmittable torque and a maximum speed of 5500 1/min determine the selection.

Benefits

  • Transmittable torque 60 Nm
  • Mounting Ø 20 mm and 22 mm for motor and drive shaft
  • Speed up to 5500 1/min
  • Mass moment of inertia 128 kgmm² for drive sizing
  • Size 56, nominal length 58 mm
  • Ambient temperature -25 to 60 °C, product weight 281 g

Applications

The coupling is used for motor mounting on electric axes and cylinders. Size 56, nominal length 58 mm and the two mounting diameters of 20 mm and 22 mm determine the fit.

Technical data

Mounting diameter 120 mm
Mounting diameter 222 mm
Size56
Nominal length58 mm
Mounting positionAny
Max. rotational speed5500 1/min
LABS (PWIS) conformityVDMA24364-B2-L
Storage temperature-25 to 60 °C
Relative air humidity0 - 95%
Ambient temperature-25 to 60 °C
Mass moment of inertia128 kgmm²
Transmittable torque60 Nm
Product weight281 g
Note on materialsRoHS compliant
Weight0.34 kg
ManufacturerFesto
Hersteller-NrEAMC-56-58-20-22
EAN4052568595692
Zolltarifnummer84836080
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMC
Temperature (max.)60
