Parallel kit motor interface 90R, 25 Nm EAMM-U-110-D60-90R-120-S1 - Festo 1203181

Festo ✓ Original product Brand new

The parallel kit EAMM-U-110-D60-90R-120-S1 from Festo places the motor parallel to the actuator and so shortens the overall length of the unit. Transmits up to 25 Nm of torque between motor and drive, plus fits actuators with code D60B and motors with code 90R. Genuine Festo accessory.

Net
€1,197.68
excl. VAT
Item FES-1203181
Manufacturer no. EAMM-U-110-D60-90R-120-S1
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The parallel kit EAMM-U-110-D60-90R-120-S1 places the motor parallel to the actuator and so shortens the overall length of the unit. At a glance: motor interface 90R, 25 Nm, actuator D60B.

Benefits

  • Transmits up to 25 Nm of torque between motor and drive
  • Fits actuators with code D60B and motors with code 90R
  • Ratio 1:1, motor speed is passed on unchanged
  • Speeds up to 5000 1/min permitted
  • Mass moment of inertia of 799 kgmm² for motor sizing
  • Frictional torque of 0.3 Nm for the torque budget

Application

Before ordering, check that the motor carries interface code 90R and the actuator matches D60B. The parallel layout of the EAMM-U-110-D60-90R-120-S1 suits installations with little space behind the actuator. EAMM-U-110-D60-90R-120-S1 can be installed in any mounting position at ambient temperatures of -10 to 60 °C.

Technical data

FeatureValue
TypeEAMM-U-110-D60-90R-120-S1
Festo part number1203181
Size110
Mounting positionany
Gear ratio1:1
Max. rotational speed5000 1/min
LABS (PWIS) conformityVDMA24364 zone III
Storage temperature-25 to 60 °C
Relative air humidity0 to 95 %
Degree of protectionIP65
Ambient temperature-10 to 60 °C
Mass moment of inertia799 kgmm²
Frictional torque independent of load0.3 Nm
Transmittable torque25 Nm
Product weight5110 g
Interface code, actuatorD60B
Interface code, motor in90R
Note on materialsRoHS compliant
Weight5 kg
ManufacturerFesto
Hersteller-NrEAMM-U-110-D60-90R-120-S1
EAN4052568414023
Zolltarifnummer84839089
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMM
Protection ratingIP65
Temperaturbereich-10-60 °C
Temperature (max.)60
