Coupling Ø 12 / 19 mm, 21 Nm EAMC-42-50-12-19-U - Festo 8101555

Festo ✓ Original product Brand new

The Festo coupling EAMC-42-50-12-19-U transmits the torque between motor shaft and drive shaft. Transmittable torque of 21 Nm for sizing the drive train, plus mounting diameters of 12 mm and 19 mm for the two shafts. Maximum rotational speed of 6000 1/min. Genuine Festo accessory.

Net
€62.17
excl. VAT
Item FES-8101555
Manufacturer no. EAMC-42-50-12-19-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The coupling EAMC-42-50-12-19-U transmits the torque between motor shaft and drive shaft. The key values: Ø 12 / 19 mm, 21 Nm, size 42.

Benefits

  • Transmittable torque of 21 Nm for sizing the drive train
  • Mounting diameters of 12 mm and 19 mm for the two shafts
  • Maximum rotational speed of 6000 1/min
  • Mass moment of inertia of 34.8 kgmm² for motor sizing
  • Nominal length of 50 mm
  • Ambient temperature -25 to 60 °C

Application

The shaft diameters of motor and drive must match the mounting bores of the EAMC-42-50-12-19-U. The mounting position of EAMC-42-50-12-19-U is freely selectable, ambient temperature range -25 to 60 °C.

Technical data

FeatureValue
TypeEAMC-42-50-12-19-U
Festo part number8101555
Mounting diameter 112 mm
Mounting diameter 219 mm
Size42
Nominal length50 mm
Mounting positionany
Max. rotational speed6000 1/min
LABS (PWIS) conformityVDMA24364-B2-L
Storage temperature-25 to 60 °C
Relative air humidity0 to 95 %
Ambient temperature-25 to 60 °C
Mass moment of inertia34.8 kgmm²
Transmittable torque21 Nm
Product weight138 g
Note on materialsRoHS compliant
Weight0.14 kg
ManufacturerFesto
Hersteller-NrEAMC-42-50-12-19-U
EAN4052568453039
Zolltarifnummer84836080
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMC
Temperature (max.)60
