Parallel kit size 145 for motor mounting, actuator S62, motor 140A or 150A, 50 Nm EAMM-U-145-S62-150A-288 - Festo 8157287

Festo ✓ Original product Brand new

Where space along the axis is tight, the parallel kit EAMM-U-145-S62-150A-288 mounts the motor (140A or 150A) next to the drive with interface S62. It transmits up to 50 Nm. Speed up to 4000 1/min, degree of protection IP40. Mass moment of inertia 2267 kgmm².

Net
€1,152.00
excl. VAT
Item FES-8157287
Manufacturer no. EAMM-U-145-S62-150A-288
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo parallel kit EAMM-U-145-S62-150A-288 mounts the motor (interface 140A or 150A) parallel to the drive (interface S62). It transmits up to 50 Nm at a ratio of 1:1.

Benefits

  • Transmittable torque 50 Nm between motor and drive
  • Speed up to 4000 1/min
  • Mass moment of inertia 2267 kgmm² as input for drive sizing
  • No-load driving torque 2 Nm
  • Ratio 1:1
  • Interfaces actuator S62, motor 140A or 150A

Applications

When sizing the axis, the mass moment of inertia of 2267 kgmm² and the transmittable torque of 50 Nm feed into the choice of motor and controller. The kit is mounted between motor (140A or 150A) and drive (S62).

Technical data

Size145
Mounting positionAny
Gear unit ratio1:1
Max. rotational speed4000 1/min
LABS (PWIS) conformityVDMA24364 zone III
Storage temperature-25 to 60 °C
Relative air humidity0 - 95%
Degree of protectionIP40
Ambient temperature-10 to 60 °C
Mass moment of inertia2267 kgmm²
Frictional torque independent of load2 Nm
Transmittable torque50 Nm
Product weight14600 g
Interface code, actuatorS62
Interface code, motor in140A, 150A
Note on materialsRoHS compliant
Weight16 kg
ManufacturerFesto
Hersteller-NrEAMM-U-145-S62-150A-288
EAN4052568600303
Zolltarifnummer84836080
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMM
Protection ratingIP40
Temperaturbereich-10-60 °C
Temperature (max.)60
