Shock absorber, self-adjusting, size 5, stroke 5 mm, 1 J per stroke DYSC-5-5-Y1F - Festo 548011

The DYSC-5-5-Y1F absorbs up to 1 J per stroke and 8000 J per hour, protecting drives, stops and workpieces from hard end-position impacts. No adjustment is needed on the DYSC in size 5 because the cushioning adapts itself to the load.

Benefits

• Energy absorption up to 1 J per stroke and 8000 J per hour
• Impact speed up to 2 m/s, mass range up to 1.5 kg
• Stop force up to 200 N, residual energy max. 0.01 J
• Return time 0.2 s, return force 0.9 N
• Mounting with lock nut, size 5
• Housing in high-alloy steel, CRC 2

Applications

The DYSC is used on linear axes, rotary actuators, grippers and stops where masses should come to rest at the end of stroke without rebound. The DYSC-5-5-Y1F is rated for -10 to 80 °C ambient temperature, any mounting position.
