Thermal flowmeter FLUX size 3, 0 to 8000 Nl/min, female thread G 1 1/2, display, pressure sensor, type 9000993510 - Riegler 148211
With the FLUX size 3 you monitor flow and consumption in the range 0 to 8000 Nl/min and detect leaks, female thread G 1 1/2. Version display, pressure sensor, operating pressure 0 to 10 bar, 0 to 50 °C, supply 12 -10 % to 24 +30 % V DC, IP 65.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With the FLUX size 3 you monitor flow and consumption in the range 0 to 8000 Nl/min and detect leaks, female thread G 1 1/2.
Version display, pressure sensor, operating pressure 0 to 10 bar, 0 to 50 °C, supply 12 -10 % to 24 +30 % V DC, IP 65.
Benefits
- Measuring range 0 to 8000 Nl/min, thermal measuring principle
- Integrated display: flow, pressure, temperature as well as current and cumulative quantities in real time
- Integrated pressure sensor: function flowmeter, flow switch, pressure gauge/switch, thermometer
- M12 male connector, 5-pin, housing aluminium
Applications
- System monitoring of flow and consumption changes
- Leakage and energy efficiency measurements
- Keep a straight section before and after the device, otherwise turbulence distorts the result
- Installed directly in the line, not intended for direct mounting on air preparation units
Technical data
| Type no. | 9000993510 |
|---|---|
| Series | FLUX |
| Size | 3 |
| Version | Analogue |
| Thread | G 1 1/2 female |
| Temperature range | 0 to 50 °C |
| Operating pressure | 0 to 10 bar |
| Flow measuring range | 0 to 8000 Nl/min |
| Flow direction | Unidirectional |
| Dimension A | 187.0 mm |
| Dimension B | 107.0 mm |
| Measuring system | Thermal |
| Medium | Unlubricated compressed air and neutral gases |
| Required purity class in accordance w. ISO 8573-1 | 4.7.3 |
| Supply voltage range | 12 -10 % to 24 +30 % V DC |
| Operating voltage | 10.8 to 31.2 V DC |
| Display | With |
| Electrical connection | M12 male connector, 5-pin |
| Current consumption | Min, 50 mA to max, 120 mA |
| Measured values output | Via cable and display (temperature only via display) |
| Housing | Aluminium |
| Digital output | PNP / NPN |
| Analogue output | 0 - 5 V DC / 0 - 10 V DC / 4 - 20 mA |
| Protection IP | IP 65 |
| Hysteresis | Adjustable |
| Pressure sensor | With |
| WiFi | Without |
| Compatible with app | No |
| Function | Flowmeter, flow switch, pressure gauge/switch, thermometer |
| Permissible voltage (max.) | 32 V DC |
| Manufacturer | Riegler |
| Hersteller-Nr | 9000993510 |
| EAN | 4047322799461 |
| Zolltarifnummer | 90261021 |
| GPSR Herstellerdaten | Riegler & Co. KG, Schützenstraße 27, DE-72574 Bad Urach, www.riegler.de |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Italy |
| Ausführung | analog |
| Material | Aluminium |
| Size BG | 3 |
| Housing material | Aluminium |
| Thread type | Internal thread |
| Operating conditions | ISO 8573-1 |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | G1 1/2 IG |
| Protection rating | IP65 |
| Temperaturbereich | 0-50 °C |
| Temperature (max.) | 50 |
