Standards-based cylinder, double-acting, Ø 25 mm, stroke 115 mm DSNU-25-115-PPS-A - Festo 593663

With its compact round design the DSNU-25-115-PPS-A delivers 115 mm of stroke and reaches 294.5 N on advance at 6 bar with a piston Ø of 25 mm and 247.4 N on return. The end positions can be sensed with proximity switches.

Benefits

• Theoretical force at 6 bar: 294.5 N advance, 247.4 N return
• Piston Ø 25 mm and stroke 115 mm, defined by the order code DSNU-25-115-PPS-A
• Self-adjusting pneumatic end-position cushioning PPS, cushioning length 17 mm
• Cylinder barrel and piston rod in high-alloy stainless steel
• Air connection G1/8, piston rod thread M10x1.25
• Prepared for proximity switches to sense the end positions (code A in the type)

Applications

In fixtures, test stations and special machines the DSNU-25-115-PPS-A moves workpieces and flaps over 115 mm. The DSNU-25-115-PPS-A is mounted with DSNU series mounting accessories. For load coupling the piston rod carries the thread M10x1.25, matching accessories for piston Ø 25 mm. For replacement please compare the type DSNU-25-115-PPS-A with the installed cylinder.
