Double-acting standard cylinder Ø 63 mm stroke 250 mm DSBC-63-250-C-PPVA - Festo 592602

Name: Double-acting standard cylinder Ø 63 mm stroke 250 mm DSBC-63-250-C-PPVA - Festo 592602
Brand: Festo
SKU: FES-592602
Price: 799.51 EUR
Availability: InStock

Festo ✓ Original product Brand new

The double-acting Festo standard cylinder DSBC-63-250-C-PPVA moves loads over a 250 mm stroke, the piston measures Ø 63 mm. The code PPVA in the type stands for pneumatic cushioning adjustable at both ends and sensing via proximity switches. It weighs 4.6 kg. The Festo part number is 592602.

Net

€799.51

excl. VAT

Item FES-592602

Manufacturer no. DSBC-63-250-C-PPVA

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Ø 63 mm piston, 250 mm stroke: these are the dimensions of the Festo standard cylinder DSBC-63-250-C-PPVA. Compressed air drives the piston both ways, so advance and return over 250 mm are powered.

Benefits

Piston Ø 63 mm, stroke 250 mm
Adjustable end-position cushioning PPV
Position detection via proximity switches
Double-acting: force in both directions
Weight 4.6 kg
Clearly identified by Festo part number 592602

Applications

Typical areas are handling, packaging and conveying, wherever a 250 mm linear stroke is required.

Technical data

Order type	DSBC-63-250-C-PPVA
Festo part number	592602
Piston diameter	63 mm
Stroke	250 mm
Mode of operation	double-acting
Cushioning	PPV: pneumatic cushioning, adjustable at both ends
Position detection	via proximity switch
Weight	4.6 kg
Customs tariff number	84123100
Manufacturer	Festo
Hersteller-Nr	DSBC-63-250-C-PPVA
Zolltarifnummer	84123100
GPSR Herstellerdaten	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Artikelzustand	New
Artikel-Authentizität	Original product
Piston Ø [mm]	63
Stroke [mm]	250
Function	double-acting
Series	DSBC
Bore (mm)	63
