Flow control valve with check function, exhaust air control, G 1/4", tube 6 mm, 0 to 10 bar

The speed of a pneumatic cylinder is set through the air volume, not through the pressure. This flow control valve with check function connects the thread G 1/4" to a tube of 6 mm outside diameter and works with exhaust air control. The throttle screw acts in one flow direction only, in the opposite direction the check valve opens fully. The materials are body Nickel-plated brass / PA 66, release ring PA 66, seals NBR, retaining claws stainless steel, cartridge ZnDC zinc-plated. The temperature range runs from -20 to +80 °C.

Advantages

• Materials body Nickel-plated brass / PA 66, release ring PA 66, seals NBR, retaining claws stainless steel, cartridge ZnDC zinc-plated, only silicone-free seals and lubricants are used during assembly.
• Operating pressure of 0 to 10 bar, which states the permissible range.
• Temperature range of -20 to +80 °C, suitable for production environments with changing load.
• Version exhaust air control, so the speed is limited on the correct side of the piston.
• Push-in connector for tube with 6 mm outside diameter, release works without tools through the release ring.

Applications

• Speed adjustment on pneumatic cylinders with 6 mm tube.
• Screwing directly into cylinder end caps with thread G 1/4".
• Avoiding the stick-slip effect on slow running actuators.
• Matching forward and return stroke in cycled handling devices.
