2/2 diaphragm valve, with forced lifting, NC, G 1, solenoid/spring, 230 V AC, DN 25, NBR, brass, coil 9154 - Norgren 8254450.9154.23049
For gases and liquids up to 10 bar: the Norgren 8254450.9154.23049 2/2 diaphragm valve reaches a Kv value of 8 m³/h at the G 1 port. 8254450.9154.23049 switches without pressure differential from 0 bar, the coil runs on 230 V AC, and NBR seals cover -10 to 90 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
At the G 1 port, the Norgren 8254450.9154.23049 2/2 diaphragm valve controls gases and liquids across a pressure range of 0 to 10 bar. Specification of 8254450.9154.23049: direct solenoid actuation with forced lifting, normally closed (NC) and coil for 230 V AC with coil code 9154.
Benefits
- Kv value 8 m³/h (Cv 9.2 gpm)
- Operating pressure 0 to 10 bar at nominal size 25 mm, vacuum-rated down to -0.9 bar
- Switches without pressure differential from 0 bar, even at low or fluctuating pressure
- Nitrile rubber (NBR) seals for fluid temperatures of -10 to 90 °C
- Coil for 230 V AC drawing 20 VA, connector DIN EN 175301-803 Form A, IP65 protection
Applications
Norgren 8254450.9154.23049 is installed in pipework for gases and liquids, G 1 port, at fluid temperatures of -10 to 90 °C and ambient temperatures of -10 to 50 °C.
Standards and compliance
For Norgren 8254450.9154.23049: The electrical connector follows DIN EN 175301-803 form A and the version is RoHS compliant, under REACH it contains an SVHC substance.
Technical data
| Manufacturer part number | 8254450.9154.23049 |
|---|---|
| Manufacturer | Norgren |
| Product type | 2/2 diaphragm valve |
| Series | 82540 |
| Valve function | 2/2 |
| Function | NC |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Diaphragm |
| Port size | G 1 |
| Nominal diameter | 25 mm |
| Operating pressure | 0 to 10 bar |
| Kv value | 8 m³/h |
| Cv flow coefficient | 9.2 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 230 V AC |
| Power consumption | 20 VA |
| Coil code | 9154 |
| Protection class | IP65 |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance present |
| WEEE | subject to WEEE |
| Customs tariff number | 84818079 |
| Hersteller-Nr | 8254450.9154.23049 |
| Zolltarifnummer | 84818079 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | 2/2-Wege-Membranventil |
| Thread | G 1 |
| Nominal size DN [mm] | 25 |
| Housing material | Brass |
| Actuation type | Electrical |
| Norm | DIN EN 175301-803 |
| Betriebsdruck max [bar] | 10 |
| Protection rating | IP65 |
| Temperaturbereich | -10-90 °C |
