2x3/2-way valve NO/NC, Mini26 design, air pilot operated - Norgren V45AC33A-X0020

The Norgren V45AC33A-X0020 is a 2x3/2-way valve with one normally open and one normally closed function (NO/NC), in the Mini26 design. The V45AC33A-X0020 is switched by pilot air and needs no electrical supply at the point of installation.

Benefits in use

• The NO/NC switching function of the V45AC33A-X0020 clearly defines the home position.
• The V45AC33A-X0020 combines two 3/2-way functions in one body and occupies just one valve position.
• Actuation of the V45AC33A-X0020: air pilot / spring.
• The V45AC33A-X0020 works within a pressure range of 0 to 10 bar.
• The V45AC33A-X0020 is rated for ambient temperatures from -15 to 50 °C.
• The body of the V45AC33A-X0020 is made of die-cast aluminium.

Applications

The V45AC33A-X0020 handles two separate 3/2 switching tasks, for example two single-acting cylinders or both chambers of a double-acting cylinder.
