Twin cylinder with plain-bearing guide Ø 10 mm 80 mm stroke DGTZ-GF-10-80-P-A - Festo 8100561

10 mm piston, 80 mm stroke and 94 N advancing force at 6 bar: the DGTZ-GF-10-80-P-A twin cylinder combines drive and guide in one ready-to-fit unit.

Benefits

• Plain-bearing guide: guide rods in plain bearings
• Force: 94 N advance and 60 N return at 6 bar (theoretical)
• Cleanroom and PWIS: class 5 to ISO 14644-1, PWIS-free to VDMA24364-Zone III
• Piston rod: high-alloy stainless steel
• Cushioning: elastic cushioning rings at both ends, impact energy up to 0.08 J

Applications

The DGTZ-GF-10-80-P-A suits lifting, stopping and pushing tasks in conveyor systems and fixture building. Operating medium for the DGTZ-GF-10-80-P-A is compressed air to ISO 8573-1:2010 [7:4:4], permitted ambient temperature -10 to 80 °C, any mounting position. For electronics, precision or battery production, this 10 mm version offers cleanroom class 5 to ISO 14644-1.
