Inductive proximity switch M4, PNP, N/O, switching distance 0.6 mm, cable 2 m DADG-D-F8-16/20 - Festo 8072857

Proximity switch DADG-D-F8-16/20 detects the position with a rated switching distance of 0.6 mm and switches via a PNP N/O output. Reduction factors according to Festo: aluminium 0.55, stainless steel 0.8, copper 0.5, brass 0.65, steel St 37 1.0.

Key benefits

• Rated switching distance 0.6 mm, assured switching distance 0.64 mm
• Repeatability 0.01 mm, switching frequency up to 5000 Hz
• PNP switching output, max. 100 mA, short-circuit proof (pulsed), reverse polarity protected
• Degree of protection IP67, housing made of steel, size M4, flush mounting
• Conforms to EN 60947-5-2, CE to EU EMC Directive
• 2 m cable, sheath made of TPE-U(PUR)

Typical use

For end position and position sensing on drives whose accessories accept a proximity switch of this size, at ambient temperatures of -25 to 70 °C.
