Connection kit size 25, stroke 80 mm, port G1/8 DADG-AK-G8-25-80 - Festo 8152401

Size 25 and stroke 80 mm determine the choice: DADG-AK-G8-25-80 is designed for exactly that. The epoxy resin adapter is tightened to max. 5 Nm, weight 53.4 g.

Why this part

• Port G1/8, max. tightening torque 3 Nm
• Mounting with max. 5 Nm tightening torque, tolerance ± 10 %
• Operating pressure 1 to 8 bar
• Adapter made of epoxy resin, seals made of FPM
• Corrosion resistance class CRC 1, rated for low corrosion stress
• Ambient temperature -10 to 60 °C

Where it is used

For drives in handling and assembly, at -10 to 60 °C ambient temperature and in paint shops with PWIS requirements.
