Input module for CTMM, 8 inputs, 24 V DC, IP65 CTMM-S1-A-8E-A-M8-4 - Festo 8047506
The input module CTMM-S1-A-8E-A-M8-4 acquires signals locally in the CTMM series. Key data: 8 inputs, nominal operating voltage 24 V DC and IP65/IP67 protection. It also offers ambient temperature -5 to 50 °C and grid dimension 28 mm.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The input module CTMM-S1-A-8E-A-M8-4 acquires signals locally in the CTMM series. The key selection criteria are 8 inputs and nominal operating voltage 24 V DC.
Advantages
- 8 inputs
- Nominal operating voltage 24 V DC
- IP65/IP67 protection for mounting directly on the machine
- Suitable for ambient temperatures of -5 to 50 °C
- Grid dimension 28 mm
- Dimensions 27 mm x 123 mm x 40 mm (W x L x H)
Application
CTMM-S1-A-8E-A-M8-4 is used when designing, extending and maintaining installations with the CTMM series.
Technical data
| Type | CTMM-S1-A-8E-A-M8-4 |
|---|---|
| Festo part number | 8047506 |
| Dimensions (W x L x H) | 27 mm x 123 mm x 40 mm |
| Grid dimension | 28 mm |
| Product weight | 75 g |
| Media temperature | -5 to 50 °C |
| Ambient temperature | -5 to 50 °C |
| Storage temperature | -20 to 40 °C |
| Degree of protection | IP65, IP67 |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| Vibration resistance | Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Shock resistance | Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 |
| Max. cable length | 30 m |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| CE mark (see declaration of conformity) | To EU EMC Directive |
| Note on materials | RoHS compliant |
| Material housing | Reinforced PA |
| Diagnostics via LED | Errors per module |
| Number of outputs | 0 |
| Nominal operating voltage DC | 24 V |
| Nominal DC operating voltage, electronics/sensors | 24 V |
| Permissible voltage fluctuations for electronics/sensors | ± 25 % |
| Intrinsic current consumption at nominal operating voltage for electronics/sensors | Typically 12 mA |
| Electrical connection input, function | Analogue input |
| Electrical connection input, connection type | 8x socket |
| Electrical connection input, connector system | M8x1, A-coded to EN 61076-2-104 |
| Electrical connection input, number of connections/cores | 4 |
| Number of inputs | 8 |
| Max. residual current of inputs per module | 0.2 A |
| Measured variable | Current |
| Signal range | 4 - 20 mA |
| Isolation channel - channel | No |
| Isolation channel - internal bus | No |
| Fuse protection (short circuit) | Internal electronic fuse |
| Weight | 0.095 kg |
| Manufacturer | Festo |
| Hersteller-Nr | CTMM-S1-A-8E-A-M8-4 |
| EAN | 4052568435295 |
| Zolltarifnummer | 85389099 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Operating voltage | 24 V DC |
| Protection rating | IP65 |
| Temperature (max.) | 50 |
