Bus interface for CPX terminal, PROFINET IRT, PROFINET RT protocol, 24 V DC, IP65 CPX-M-FB45 - Festo 8110371

Festo ✓ Original product Brand new

The Festo bus interface CPX-M-FB45 connects the CPX terminal to the higher-level controller. Key data: PROFINET IRT, PROFINET RT protocol, nominal operating voltage 24 V DC and IP65/IP67 protection. Further data: ambient temperature -5 to 50 °C and dimensions 50 mm x 107 mm x 80 mm (W x L x H).

Net
€1,259.84
excl. VAT
Item FES-8110371
Manufacturer no. CPX-M-FB45
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The bus interface CPX-M-FB45 connects the CPX terminal to the higher-level controller. The main data are PROFINET IRT, PROFINET RT protocol and nominal operating voltage 24 V DC.

Advantages

  • Fieldbus connection via PROFINET IRT, PROFINET RT
  • Nominal operating voltage 24 V DC
  • IP65/IP67 protection for mounting directly on the machine
  • Suitable for ambient temperatures of -5 to 50 °C
  • Dimensions 50 mm x 107 mm x 80 mm (W x L x H)
  • Corrosion resistance class CRC 0 (no corrosion stress)

Application

CPX-M-FB45 is used when designing, extending and maintaining installations with the CPX terminal.

Technical data

TypeCPX-M-FB45
Festo part number8110371
ProtocolPROFINET IRT, PROFINET RT
Dimensions (W x L x H)50 mm x 107 mm x 80 mm
Product weight280 g
Ambient temperature-5 to 50 °C
Storage temperature-20 to 70 °C
Degree of protectionIP65, IP67
Corrosion resistance class CRC0 - No corrosion stress
LABS (PWIS) conformityVDMA24364-B2-L
ApprovalRCM
Note on materialsRoHS compliant
Material housingDie-cast aluminium
LED display, product-specificM: Modify, parameterisation, PL: Load supply, PS: Electronics supply, sensor supply, SF: System errors
LED display, bus-specificM/P: Maintenance/PROFIenergy, NF: Network error, TP1: Network active port 1, TP2: Network active port 2
Device-specific diagnosticsChannel-oriented and module-oriented diagnostics, Undervoltage of modules, Diagnostics memory
Operator controlsDIL switch
Field bus interface2x SCRJ push-pull socket, AIDA
Max. address volume, inputs64 byte
Max. address volume, outputs64 byte
ParameterisationDiagnostic behaviour, Fail-safe response, Forcing of channels, Signal setup, System parameters
Baud rate100 Mbit/s
Configuration supportGSDML file
Additional functionsChannel-oriented diagnostics via fieldbus, LLDP, Message Queuing Telemetry Transport, Manufacturing Resource Planning, MRPD, PROFIenergy, PROFIsafe, S2 system redundancy, Start-up parameterisation in plain text via fieldbus, System status can be mapped using process data, Additional diagnostic interface for operator units
Operational voltage range DC18 to 30 V
Nominal operating voltage DC24 V
Intern power consumption nominal operating voltageTyp. 145 mA
Weight0.28 kg
ManufacturerFesto
Hersteller-NrCPX-M-FB45
EAN4052568560898
Zolltarifnummer85176200
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Housing materialDie-cast aluminium
Operating voltage24 V DC
Protection ratingIP65
Temperature (max.)50
