System forwarding for CPX-AP-A, 24 V DC, grid dimension 50.1 mm CPX-AP-A-W-1-PP-5P - Festo 8169617
The Festo system forwarding CPX-AP-A-W-1-PP-5P forwards communication and power within the CPX-AP-A system. The data sheet lists nominal operating voltage 24 V DC, nominal current 10 A and ambient temperature -20 to 50 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The system forwarding CPX-AP-A-W-1-PP-5P forwards communication and power within the CPX-AP-A system. For system design, the relevant data are nominal operating voltage 24 V DC and nominal current 10 A.
Advantages
- Nominal operating voltage 24 V DC
- Nominal current 10 A
- Suitable for ambient temperatures of -20 to 50 °C
- Grid dimension 50.1 mm
- Dimensions 50.1 mm x 153 mm x 45.6 mm (W x L x H)
- Corrosion resistance class CRC 1 (low corrosion stress)
Application
CPX-AP-A-W-1-PP-5P is used when designing, extending and maintaining installations with the CPX-AP-A system.
Technical data
| Type | CPX-AP-A-W-1-PP-5P |
|---|---|
| Festo part number | 8169617 |
| Dimensions (W x L x H) | 50.1 mm x 153 mm x 45.6 mm |
| Grid dimension | 50.1 mm |
| Type of mounting | On DIN rail via accessories, With through-hole for M5 screw with accessories, With through-hole for M6 screw with accessories |
| Product weight | 182 g |
| Mounting position | Any, on H-rail: horizontal |
| Ambient temperature | -20 to 50 °C |
| Note on ambient temperature | Observe ambient temperature derating according to IEC 61131-2:2017 |
| Storage temperature | -20 to 70 °C |
| Relative air humidity | 5 - 95%, Non-condensing |
| Nominal altitude of use | ≤ 2000 m ASL (> 79.5 kPa) |
| Max. installation height | 3500 m |
| Note on max. installation height | Observe ambient temperature derating according to IEC 61131-2:2017 |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| Vibration resistance | Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Note on vibration resistance | Transport application test with severity class 1 to FN 942017-4 and EN 60068-2-6 |
| Shock resistance | Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 |
| Note on shock resistance | 30 g/11 ms to EN 60068-2-27, SG1 on DIN rail, SG2 on direct mounting, Shock test with severity level 1 to FN 942017-5 and EN 60068-2-27 |
| Protection class | III |
| Overvoltage category | II |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Fire test material | UL94 V-0 (housing) |
| Note on materials | RoHS compliant, Free of halogen, Free of phosphoric acid ester |
| Material housing | Reinforced PA |
| Material flange | Nickel-plated die-cast zinc |
| Material screws | Nickel-plated steel |
| Material seals | Polyurethane foam |
| Power transmission, function | Outgoing electronics/sensors and load and functional earth |
| Power transmission, connection type | Plug |
| Power transmission, connection technology | Push-pull to IEC 61076-3-126 |
| Power transmission, number of pins/wires | 5 |
| Note regarding operating voltage | SELV/PELV fixed power supplies required, Note the voltage drop |
| Note on nominal operating voltage DC | 2X24 V [XD2,PS,PL], Protected Extra-Low-Voltage to IEC 60204-1 |
| Nominal operating voltage DC of load | 24 V |
| Nominal DC operating voltage, electronics/sensors | 24 V |
| Nominal current | 10 A |
| Max. power supply | 2 x 10 A (external fuse required) |
| Potential separation between the supply voltages electronics/sensor technology and load/valves | Yes |
| Weight | 0.195 kg |
| Manufacturer | Festo |
| Hersteller-Nr | CPX-AP-A-W-1-PP-5P |
| EAN | 4052568609733 |
| Zolltarifnummer | 85369095 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Operating voltage | 24 V DC |
| Temperaturbereich | -20-50 °C |
| Temperature (max.) | 50 |
