System supply CPX-AP-A-S-1-7/8-5P - Festo 8129255
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Dimensions (W x L x H) | 50.1 mm x 122 mm x 35 mm |
|---|---|
| Grid dimension | 50.1 mm |
| Type of mounting | On DIN rail via accessories, With through-hole for M5 screw with accessories, With through-hole for M6 screw with accessories |
| Product weight | 113 g |
| Mounting position | Any, on H-rail: horizontal |
| Ambient temperature | -20 ... 50 °C |
| Note on ambient temperature | Observe ambient temperature derating according to IEC 61131-2:2017 |
| Storage temperature | -20 ... 70 °C |
| Relative air humidity | 5 - 95%, Non-condensing |
| Nominal altitude of use | <= 2000 m ASL (> 79.5 kPa) |
| Max. installation height | 3500 m |
| Note on max. installation height | Observe ambient temperature derating according to IEC 61131-2:2017 |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| Vibration resistance | Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Note on vibration resistance | Transport application test with severity class 1 to FN 942017-4 and EN 60068-2-6 |
| Shock resistance | Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 |
| Note on shock resistance | 30 g/11 ms to EN 60068-2-27, SG1 on DIN rail, SG2 on direct mounting, Shock test with severity level 1 to FN 942017-5 and EN 60068-2-27 |
| Protection class | III |
| Overvoltage category | II |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Fire test material | UL94 V-0 (housing) |
| Note on materials | RoHS compliant, Free of halogen, Free of phosphoric acid ester |
| Material housing | Reinforced PA |
| Material screws | Nickel-plated steel |
| Material seals | Polyurethane foam |
| Material thread seal | TPE-U(PU) |
| Power supply, function | Incoming electronics/sensors and load and functional earth |
| Power supply, connection type | Plug |
| power supply, connection system | 7/8“ to NFPA/T3.5.29 |
| Power supply, connection pattern | 00995967 |
| Power supply, number of pins/wires | 5 |
| Note regarding operating voltage | SELV/PELV fixed power supplies required, Note the voltage drop |
| Note on nominal operating voltage DC | 2x24 V [XD1,PS,PL], Protected Extra-Low-Voltage to IEC 60204-1 |
| Nominal operating voltage DC of load | 24 V |
| Nominal DC operating voltage, electronics/sensors | 24 V |
| Power supply, conductor diameter | 1.5 mm² |
| Nominal current | 8 A |
| Max. power supply | 2 x 8 A (external fuse required) |
| Potential separation between the supply voltages electronics/sensor technology and load/valves | Yes |
| Weight | 0.12 kg |
| Manufacturer | Festo |
| Hersteller-Nr | CPX-AP-A-S-1-7/8-5P |
| EAN | 4052568600426 |
| Zolltarifnummer | 85369095 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
