Manifold block single-acting G1/4 380 l/min CAPS-M1-VDE1-S-A-AL-G14-V - Festo 8154577
The Festo CAPS-M1-VDE1-S-A-AL-G14-V manifold block is mounted in accordance with VDI/VDE 3845 and feeds compressed air single-acting at 380 l/min standard nominal flow to the actuator. Port G1/4. Safety position: pneumatic output 2 exhausted. Mounting in accordance with VDI/VDE 3845.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo CAPS-M1-VDE1-S-A-AL-G14-V manifold block is mounted in accordance with VDI/VDE 3845 and feeds compressed air single-acting at 380 l/min standard nominal flow to the actuator.
Why choose it
- Standard nominal flow rate 380 l/min
- Safety position: pneumatic output 2 exhausted
- Mounting in accordance with VDI/VDE 3845
- LABS (PWIS) conformity VDMA24364 zone III
- Housing made of aluminium, powder-coated
Typical applications
Compressed air is connected via G1/4. Dimensions 65 mm x 104 mm x 28 mm.
Technical data
| Type | CAPS-M1-VDE1-S-A-AL-G14-V |
|---|---|
| Festo part number | 8154577 |
| Dimensions (W x L x H) | 65 mm x 104 mm x 28 mm |
| Mode of operation | Single-acting |
| Design characteristics | Safety position: pneumatic output 2 exhausted |
| Standard nominal flow rate (standardised to DIN 1343) | 380 l/min |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Product weight | 465 g |
| Type of mounting | in accordance with VDI/VDE 3845 |
| Pneumatic connection | G1/4 |
| Note on materials | RoHS compliant |
| Material screws | High-alloy stainless steel |
| Material housing | Aluminium, powder-coated |
| Weight | 0.49 kg |
| Manufacturer | Festo |
| Hersteller-Nr | CAPS-M1-VDE1-S-A-AL-G14-V |
| EAN | 4052568577223 |
| Zolltarifnummer | 76169990 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/4 |
