Directional Spool Valve 4WE10C5X/DEG110N9K4/V - Bosch Rexroth R901542202

Name: Directional Spool Valve 4WE10C5X/DEG110N9K4/V - Bosch Rexroth R901542202
Brand: Bosch Rexroth
SKU: BRR-R901542202
Price: 289.91 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Fluoroelastomer and spool symbol C meet inside the 4WE10C5X/DEG110N9K4/V. The unit passes 135 l/min in size 10, holds a maximum operating pressure of 350 bar and is actuated from 110 V DC at a weight of 4 kg.

Net

€289.91

excl. VAT

Item BRR-R901542202

Manufacturer no. R901542202

Question about this item

Datasheet (PDF) User manual 10 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Raised demands on the sealing material rule the standard build out. The 4WE10C5X/DEG110N9K4/V works on FKM and carries up to 135 l/min at a maximum operating pressure of 350 bar.

Benefits

FKM seals fitted at the factory, hydraulic fluid HL.
135 l/min flow in size 10 at a maximum of 350 bar.
Spool symbol C with two switching positions on four ports.
110 V DC, 3-pole connector (2 + PE) to EN 175301-803.
4 kg weight, interface ISO 4401-05-04-0-05, UKCA to SI2016/1091.

Application

The valve is placed where operating conditions call for a fluoroelastomer while the circuit carries 135 l/min. Subplate and wiring follow the standardised patterns.

Manufacturer

Bosch Rexroth lists the valve under material number R901542202 in product family WE10../E.

Technical data

Conformity description	UKCA - Low-Voltage Directive SI2016/1091
Connection diagram	ISO 4401-05-04-0-05
Max. flow	135 l/min
Product family	WE10../E
Type of connection	Subplate mounting
Conformity	UKCA
Supply voltage	110 VDC
Number of switching positions	2
Hydraulic fluid	HL
Number of ports	4
Electrical connection description	Connector 3-pole (2 + PE) according to EN 175301-803
Spool symbol	Symbol C
Operating pressure, max.	350 bar
Size	10
Seals	FKM
Electrical connector	Connector, 3-pole (2 + PE)
Type of actuation	with solenoid actuation
Weight	4 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901542202
Zolltarifnummer	84812010
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
