If the command value has to reach up to the permitted operating pressure, the pressure rating must suit. The DBEM20-7X/350YG24K4M works in the 350 bar rating and accepts up to 550 l/min in size 20, driven by external electronics.
Prop-Druckbegrenzung SVT DBEM20-7X/350YG24K4M - Bosch Rexroth R901353054
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,326.56
Item
BRR-R901353054
Manufacturer no.
R901353054
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901353054
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R901353054
Frequently Bought Together
-
This Item:
€2,326.56
-
Kugelhahn AB21-20/G 3/4-315 V - Bosch Rexroth R900028480
€69.24
-
Kegelrollenlager 32968 J - Bosch Rexroth R916412700
€3,158.97
Total price
The pressure rating defines which range the command value covers. On the DBEM20-7X/350YG24K4M it is 350 bar, that is the full permitted operating pressure of the unit. Throughput reaches 550 l/min.
Benefits
- Pressure rating 350 bar, equal to the maximum operating pressure
- Up to 550 l/min in size 20 to porting pattern ISO 6264
- Symbol P to T, P to Y across four ports
- Electrical with external electronics, 24 V DC supply
- Pilot-operated seat valve, NBR seals for HL hydraulic fluid
- 3-pole connector (2 + PE) to EN 175301-803, weight 5.3 kg
Technical data
| Connection diagram | ISO 6264 |
| Max. flow | 550 l/min |
| Product family | DBEM(E) |
| Type of connection | Subplate mounting |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 4 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | P nach T, P nach Y |
| Operating pressure, max. | 350 bar |
| Size | 20 |
| Seals | NBR |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | Electrical with external electronics |
| Weight | 5.3 kg |
Application
In presses and test rigs driven across the whole pressure band the control uses the full command value range. Intermediate levels can be reached in the sequence without touching the unit. The pilot stage brings 550 l/min into effect.
Manufacturer
Bosch Rexroth, material number R901353054. The type designation DBEM20-7X/350YG24K4M names size, pressure rating and porting.
| Hersteller-Nr | R901353054 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 5.300000 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
