Where pilot oil and pilot drain have to run separately, the relief valve needs ports of its own. The 315XY version of the DBW52BP2 brings ports X and Y along and caps pressure up to 315 bar at flows to 2000 l/min.
Pressure Relief Valve DBW52BP2-3X/315XYU6EG24N9DL - Bosch Rexroth R900617195
BOSCH REXROTH
Original product
Net price (excl. VAT)
€10,699.95
Item
BRR-R900617195
Manufacturer no.
R900617195
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R900617195
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R900617195
Frequently Bought Together
-
This Item:
€10,699.95
-
HY-RückschlagventilS20A1.0/SO68 - Bosch Rexroth R900390434
€189.33
-
Pressure Reducing Valve Z ZDR10DB3-5X/150YMV/12 - Bosch Rexroth R901352456
€611.24
Total price
The pilot stage of a large relief valve reacts badly to back pressure in the tank gallery. In the 315XYU6EG24N9DL version, the DBW52BP2-3X routes pilot oil and pilot drain through separate X and Y ports and works up to 315 bar.
Benefits
- Separate pilot ports X and Y - the pilot stage stays decoupled from pressure in the tank gallery.
- Up to 2000 l/min in size 52 at a maximum operating pressure of 315 bar.
- Adjustment range 4 to 315 bar through an internal hexagon with protective cap.
- Symbol B, 2 ports, 2 switching positions, solenoid actuation on 24 VDC.
- 28.66 kg, NBR seals, pilot-operated seat valve, subplate mounting.
Technical data
| Max. flow | 2000 l/min |
| Product family | DB(W)52 |
| Type of connection | Subplate mounting |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 2 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | B |
| Operating pressure, max. | 315 bar |
| Size | 52 |
| Seals | NBR |
| Electrical connector | Cable gland |
| Type of actuation | with solenoid actuation |
| Weight | 28.66 kg |
Application
Intended for systems with long return lines or return filters, where the tank gallery builds up counter pressure. The Y port lets pilot flow reach tank unpressurised, which keeps the relief setting stable. Both galleries have to be provided in the manifold.
Manufacturer
Bosch Rexroth, material number R900617195, type DBW52BP2-3X/315XYU6EG24N9DL, DB(W)52 product family, component series 3X.
| Weight | 28.660000 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Hersteller-Nr | R900617195 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
