Compact cylinder double-acting Ø 63 mm stroke 10 mm ADN-S-63-10-A-P - Festo 8092126

63 mm piston, 10 mm stroke, 1870 N advance and 1750 N return force at 6 bar: the double-acting compact cylinder ADN-S-63-10-A-P fits fixtures where a standard cylinder is too long.

Benefits at a glance

• Easy sizing: 1870 N forward and 1750 N back at 6 bar according to Festo
• Quiet stop: elastic cushioning at both ends absorbs 0.64 J in the end positions
• Additional PTFE piston guide: extra guidance for the piston, 63 mm diameter
• Wide pressure range: 0.4 to 10 bar operating pressure, 0 to 80 °C ambient temperature
• Corrosion resistance class CRC 1: piston rod in high-alloy stainless steel
• Cleanroom and paint shops: class 5 to ISO 14644-1, LABS (PWIS) conformity VDMA24364-B2-L

Applications

Pressing, joining and clamping larger workpieces are typical uses of the ADN-S-63-10-A-P with a 63 mm diameter. The short 10 mm stroke keeps cycle times short and air consumption low. The 63 mm cylinder is fastened via through-holes, female threads or Festo accessories, the piston rod has a male thread. For sizing, Festo states 505 g basic weight and 175 g moving mass at 0 mm stroke, plus 76 g and 16 g respectively per 10 mm stroke.
