Double-acting compact cylinder Ø 63 mm stroke 45 mm ADN-63-45-A-P-A-Q - Festo 579021

The Festo compact cylinder ADN-63-45-A-P-A-Q moves its load over a 45 mm stroke, the piston measures Ø 63 mm. According to type code ADN-63-45-A-P-A-Q, the cylinder is prepared for end-position sensing with proximity switches. Being double-acting, the Ø 63 mm piston is driven by compressed air in both directions.

Benefits at a glance

• Piston Ø 63 mm, stroke 45 mm
• Cushioning P: elastic rings at both ends
• Piston rod with male thread
• Position detection via proximity switches
• Double-acting: force in both directions
• Weight 0.95 kg

Use

The ADN-63-45-A-P-A-Q handles pushing, lifting and ejecting movements over 45 mm in assembly systems, packaging machines and feeding equipment.
