Double-acting compact cylinder Ø 63 mm stroke 120 mm ADN-63-120-I-P-A - Festo 563117

With a 120 mm stroke and a Ø 63 mm piston, the ADN compact cylinder ADN-63-120-I-P-A covers short linear movements. According to type code ADN-63-120-I-P-A, the cylinder is prepared for end-position sensing with proximity switches. Being double-acting, the Ø 63 mm piston is driven by compressed air in both directions.

Key benefits

• Piston Ø 63 mm, stroke 120 mm
• Elastic end-position cushioning P at both ends
• Piston rod with female thread
• Position detection via proximity switches
• Double-acting: force in both directions
• Weight 1.4 kg

Typical applications

Typical tasks are ejecting, shifting and positioning workpieces over 120 mm, wherever a standard cylinder would be too long.
