Compact cylinder double-acting Ø 63 mm stroke 100 mm ADN-63-100-A-P-A - Festo 8140020

The Festo ADN-63-100-A-P-A is a double-acting compact cylinder with a 63 mm piston and 100 mm stroke. At 6 bar it reaches 1870 N advance and 1750 N return force. The data below is derived from the type code ADN-63-100-A-P-A and Festo data of the ADN series with a 63 mm piston.

Benefits

• Easy sizing: 1870 N forward and 1750 N back at 6 bar according to Festo
• Gentle end positions: elastic cushioning rings at both ends, impact energy up to 1.3 J
• Position sensing: prepared for proximity switches, port G1/8
• Flexible use: operating pressure 0.6 to 10 bar
• Attachment: piston rod with male thread, 63 mm piston

Applications

With a 63 mm piston the ADN-63-100-A-P-A covers force-intensive tasks such as pressing, press-fitting and clamping heavy workpieces. With 100 mm stroke it also handles longer pushing and feed travel.
