Double-acting compact cylinder Ø 50 mm stroke 70 mm ADN-50-70-A-P-A - Festo 572851

For 70 mm of travel, the double-acting ISO 21287 compact cylinder ADN-50-70-A-P-A with a Ø 50 mm piston produces a theoretical force of 1178 N at 6 bar, and 1057 N on the return. The piston rod with male thread M12x1.25 takes the tooling or load, the air port is G1/8. The ADN-50-70-A-P-A operates in a pressure range of 0.6 to 10 bar and at -20 to 80 °C.

Benefits

• 1178 N advance and 1057 N return force at 6 bar
• Elastic end-position cushioning P at both ends, up to 1 J impact energy
• Piston rod with male thread M12x1.25 made of high-alloy steel
• Position detection via proximity switches
• Operating pressure 0.6 to 10 bar
• Mounting dimensions to ISO 21287, interchangeable with other compact cylinders to this standard

Applications

Typical tasks are ejecting, shifting and positioning workpieces over 70 mm, wherever a standard cylinder would be too long. Installed in any orientation, the ADN-50-70-A-P-A runs on compressed air to ISO 8573-1:2010 [7:4:4].
