Double-acting compact cylinder Ø 50 mm stroke 50 mm ADN-50-50-I-P-A-"M8"K5 - Festo 589545

The Festo compact cylinder ADN-50-50-I-P-A-"M8"K5 moves its load over a 50 mm stroke, the piston measures Ø 50 mm. The letter A after the cushioning code in type ADN-50-50-I-P-A-"M8"K5 stands for position detection via proximity switches. Compressed air drives the piston both ways, so advance and return over 50 mm are powered.

Benefits at a glance

• Piston Ø 50 mm, stroke 50 mm
• Cushioning P: elastic rings at both ends
• Piston rod with female thread
• End positions can be sensed with proximity switches
• Double-acting: force in both directions
• Weight 0.75 kg

Use

Typical tasks are ejecting, shifting and positioning workpieces over 50 mm, wherever a standard cylinder would be too long.
