Compact cylinder, double-acting, Ø 40 mm stroke 35 mm ADN-40-35-A-P-A - Festo 8179031

The compact cylinder ADN-40-35-A-P-A is made for fixtures with little space: piston Ø 40 mm, stroke 35 mm, 754 N advance force at 6 bar. The piston rod ends in an M10x1.25 male thread.

Benefits

• Elastic cushioning rings at both ends, permissible impact energy 0.7 J
• Theoretical force at 6 bar: 754 N advance, 686 N return
• Dimensions to ISO 21287, so standard mounting accessories fit directly
• Cleanroom-suitable, class 5 to ISO 14644-1, PWIS (LABS) conformity VDMA24364-B1/B2-L
• Operating pressure 0.6 to 10 bar, ambient temperature -20 to 80 °C
• Mounting via through-holes or female thread in the cover, port G1/8

Applications

In tooling and fixture construction the ADN-40-35-A-P-A turns short 35 mm strokes into 754 N of force. It runs on compressed air to ISO 8573-1:2010 [7:4:4] at 0.6 to 10 bar, lubricated operation is possible.
