Double-acting compact cylinder Ø 40 mm stroke 200 mm ADN-40-200-A-P-A - Festo 566934

With a 200 mm stroke and a Ø 40 mm piston, the ADN compact cylinder ADN-40-200-A-P-A covers short linear movements. According to type code ADN-40-200-A-P-A, the cylinder is prepared for end-position sensing with proximity switches. Being double-acting, the Ø 40 mm piston is driven by compressed air in both directions.

Key benefits

• Piston Ø 40 mm, stroke 200 mm
• Cushioning P: elastic rings at both ends
• Piston rod with male thread
• End positions can be sensed with proximity switches
• Double-acting: force in both directions
• Weight 1.1 kg

Typical applications

Typical tasks are ejecting, shifting and positioning workpieces over 200 mm, wherever a standard cylinder would be too long.
