Double-acting compact cylinder Ø 40 mm stroke 20 mm ADN-40-20-A-P-A-S20-"M12"K5 - Festo 609947
Ø 40 mm piston and 20 mm stroke in a short design: the Festo compact cylinder ADN-40-20-A-P-A-S20-"M12"K5 fits where installation length is limited. Elastic cushioning rings at both ends catch the piston in its end positions. The piston rod with male thread takes the tooling or load. Weight 0.44 kg.
Net
excl. VAT
€143.18
Item
FES-609947
Manufacturer no.
ADN-40-20-A-P-A-S20-"M12"K5
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo compact cylinder ADN-40-20-A-P-A-S20-"M12"K5 moves its load over a 20 mm stroke, the piston measures Ø 40 mm. According to type code ADN-40-20-A-P-A-S20-"M12"K5, the cylinder is prepared for end-position sensing with proximity switches. Compressed air drives the piston both ways, so advance and return over 20 mm are powered.
Key benefits
- Piston Ø 40 mm, stroke 20 mm
- Cushioning P: elastic rings at both ends
- Piston rod with male thread
- Position detection via proximity switches
- Double-acting: force in both directions
- Weight 0.44 kg
Typical applications
The short 20 mm stroke makes the cylinder a choice for stoppers, hold-downs and clamping fixtures with little installation space.
Technical data
| Order type | ADN-40-20-A-P-A-S20-"M12"K5 |
|---|---|
| Festo part number | 609947 |
| Piston diameter | 40 mm |
| Stroke | 20 mm |
| Mode of operation | double-acting |
| Piston rod end | male thread |
| Cushioning | P: elastic cushioning rings/plates at both ends |
| Position detection | via proximity switch |
| Further type code elements | S20, "M12"K5 |
| Weight | 0.44 kg |
| Customs tariff number | 84123100 |
| Manufacturer | Festo |
| Hersteller-Nr | ADN-40-20-A-P-A-S20-"M12"K5 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Piston Ø [mm] | 40 |
| Stroke [mm] | 20 |
| Function | double-acting |
| Series | ADN |
| Bore (mm) | 40 |
Downloads
Questions about this item
Any other question?
Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
