Double-acting compact cylinder Ø 40 mm stroke 117 mm ADN-40-117-A-PPS-A - Festo 583207
Ø 40 mm piston and 117 mm stroke in a short design: the Festo compact cylinder ADN-40-117-A-PPS-A fits where installation length is limited. The PPS pneumatic end-position cushioning adjusts itself to load and speed. The load is coupled via the piston rod with male thread. Weight 0.8 kg.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo compact cylinder ADN-40-117-A-PPS-A moves its load over a 117 mm stroke, the piston measures Ø 40 mm. According to type code ADN-40-117-A-PPS-A, the cylinder is prepared for end-position sensing with proximity switches. Being double-acting, the Ø 40 mm piston is driven by compressed air in both directions.
Benefits
- Piston Ø 40 mm, stroke 117 mm
- PPS end-position cushioning without adjustment
- Piston rod with male thread
- End positions can be sensed with proximity switches
- Double-acting: force in both directions
- Weight 0.8 kg
Applications
Typical tasks are ejecting, shifting and positioning workpieces over 117 mm, wherever a standard cylinder would be too long.
Technical data
| Order type | ADN-40-117-A-PPS-A |
|---|---|
| Festo part number | 583207 |
| Piston diameter | 40 mm |
| Stroke | 117 mm |
| Mode of operation | double-acting |
| Piston rod end | male thread |
| Cushioning | PPS: self-adjusting pneumatic end-position cushioning |
| Position detection | via proximity switch |
| Weight | 0.8 kg |
| Customs tariff number | 84123100 |
| Manufacturer | Festo |
| Hersteller-Nr | ADN-40-117-A-PPS-A |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Piston Ø [mm] | 40 |
| Function | double-acting |
| Series | ADN |
| Bore (mm) | 40 |
Downloads
Questions about this item
Any other question?
Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
