Double-acting compact cylinder Ø 32 mm stroke 5 mm ADN-32-5-A-P-A-S2 - Festo 593669

Ø 32 mm piston, 5 mm stroke: the double-acting compact cylinder ADN-32-5-A-P-A-S2 from the ADN series is the Festo version with part number 593669. The letter A after the cushioning code in type ADN-32-5-A-P-A-S2 stands for position detection via proximity switches. Being double-acting, the Ø 32 mm piston is driven by compressed air in both directions.

Key benefits

• Piston Ø 32 mm, stroke 5 mm
• Elastic end-position cushioning P at both ends
• Piston rod with male thread
• End positions can be sensed with proximity switches
• Double-acting: force in both directions
• Weight 0.3 kg

Typical applications

Typical tasks are clamping, locking and separating, for example in assembly lines and test stations where 5 mm of stroke is sufficient.
