Double-acting compact cylinder Ø 20 mm stroke 30 mm ADN-20-30-ELB-A-P-A - Festo 609258

Ø 20 mm piston, 30 mm stroke: the double-acting compact cylinder ADN-20-30-ELB-A-P-A from the ADN series is the Festo version with part number 609258. The letter A after the cushioning code in type ADN-20-30-ELB-A-P-A stands for position detection via proximity switches. Being double-acting, the Ø 20 mm piston is driven by compressed air in both directions.

Benefits at a glance

• Piston Ø 20 mm, stroke 30 mm
• Elastic end-position cushioning P at both ends
• Piston rod with male thread
• Position detection via proximity switches
• Double-acting: force in both directions
• Weight 0.3 kg

Use

In handling and fixture construction the cylinder moves parts over 30 mm, for example as an ejector, pusher or lifting unit.
