Double-acting compact cylinder Ø 20 mm stroke 25 mm ADN-20-25-I-P-A-S2 - Festo 579118

With a 25 mm stroke and a Ø 20 mm piston, the ADN compact cylinder ADN-20-25-I-P-A-S2 covers short linear movements. The letter A after the cushioning code in type ADN-20-25-I-P-A-S2 stands for position detection via proximity switches. Being double-acting, the Ø 20 mm piston is driven by compressed air in both directions.

Key benefits

• Piston Ø 20 mm, stroke 25 mm
• Cushioning P: elastic rings at both ends
• Piston rod with female thread
• Position detection via proximity switches
• Double-acting: force in both directions
• Weight 0.195 kg

Typical applications

Typical tasks are clamping, locking and separating, for example in assembly lines and test stations where 25 mm of stroke is sufficient.
