Double-acting compact cylinder Ø 12 mm stroke 20 mm ADN-12-20-I-P-A-S11 - Festo 604097

With a 20 mm stroke and a Ø 12 mm piston, the ADN compact cylinder ADN-12-20-I-P-A-S11 covers short linear movements. According to type code ADN-12-20-I-P-A-S11, the cylinder is prepared for end-position sensing with proximity switches. Compressed air drives the piston both ways, so advance and return over 20 mm are powered.

Benefits at a glance

• Piston Ø 12 mm, stroke 20 mm
• Cushioning P: elastic rings at both ends
• Piston rod with female thread
• Position detection via proximity switches
• Double-acting: force in both directions
• Weight 0.085 kg

Use

With a 20 mm stroke, the ADN-12-20-I-P-A-S11 suits clamping, holding and stopping tasks in fixtures that need only a few millimetres of travel.
