Double-acting compact cylinder Ø 12 mm stroke 10 mm ADN-12-10-I-P-A-10K8 - Festo 572566

The Festo compact cylinder ADN-12-10-I-P-A-10K8 moves its load over a 10 mm stroke, the piston measures Ø 12 mm. The load is coupled via the piston rod with female thread. The letter A after the cushioning code in type ADN-12-10-I-P-A-10K8 stands for position detection via proximity switches.

Key benefits

• Piston Ø 12 mm, stroke 10 mm
• Elastic end-position cushioning P at both ends
• Piston rod with female thread
• Position detection via proximity switches
• Double-acting: force in both directions
• Weight 0.075 kg

Typical applications

With a 10 mm stroke, the ADN-12-10-I-P-A-10K8 suits clamping, holding and stopping tasks in fixtures that need only a few millimetres of travel.
