Reed cylinder switch ST9-R3-K03U-030, for 9 mm groove, 3 m cable, tin-plated wire ends - Aventics 0830100390
The Aventics ST9-R3-K03U-030 from the ST9 series switches when the piston position is reached, 3 m cable, tin-plated wire ends. Operating voltage 12 to 24 V DC and 12 to 24 V AC, switching current up to 0.13 A. Use from -20 to 80 °C with protection class IP67 and IP65.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Aventics ST9-R3-K03U-030 from the ST9 series switches when the piston position is reached, 3 m cable, tin-plated wire ends.
Benefits
- Mounting: the sensor is inserted into the 9 mm groove and clamped.
- Electronics reverse polarity protected, which protects against wiring errors during commissioning.
- When adjusting on the cylinder, the yellow LED helps to find the switching point.
- Protection class IP67 and IP65 for installation in the machine area.
- Usable at ambient temperatures from -20 to 80 °C.
- Shock resistant to 100 g / 11 ms and vibration resistant at 60 g (50 to 2000 Hz), suitable for moving machine parts.
Applications
Mounts directly on cylinders of series KHZ. Typical use is end-position sensing on pneumatic cylinders in assembly, handling and packaging machines, where the ST9-R3-K03U-030 replaces mechanical limit switches.
Technical data
| Feature | Value |
|---|---|
| Type | ST9-R3-K03U-030 |
| Part number | 0830100390 |
| Direct mounting for series | KHZ |
| Slot width | 9 mm groove |
| Cable | with cable |
| Contact type | Reed |
| Operating voltage DC | 12 to 24 V DC |
| Operational voltage AC | 12 to 24 V AC |
| Switching capacity | 3 W / 5 VA |
| Protection class | IP67, IP65 |
| Ambient temperature | -20 to 80 °C |
| Voltage drop U at Imax | I*Rs |
| Protective resistor for reed | 1.3 Ω |
| Max DC switching current | 0.13 A |
| Max AC switching current | 0.2 A |
| Switching point precision | ±0.1 mT |
| LED status display | Yellow |
| Electrical connection 2, type | without wire end ferrule, tin-plated |
| Electrical connection 2, number of poles | 3-pin |
| Short circuit resistance | Protected against polarity reversal |
| Shock resistance | 100 g / 11 ms |
| Vibration resistance | 60 g (50 to 2000 Hz) |
| Cable length L | 3 m |
| Housing material | Epoxy resin |
| Weight | 0.06 kg |
| Manufacturer | Aventics |
| Hersteller-Nr | 0830100390 |
| Zolltarifnummer | 85365080 |
| GPSR Herstellerdaten | AVENTICS GmbH, Ulmer Straße 4, DE-30880 Laatzen, aventics.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
| Protection rating | IP67 |
| Temperaturbereich | -20-80 °C |
