90° bend, male thread R 3/4" to female thread Rp 3/4", length 50 mm, zinc plated malleable cast iron

Where a change of direction is due, the 90° bend replaces the bent section of pipe. The male thread R 3/4" and the female thread Rp 3/4" are available for the connection. The overall length is stated as 50 mm. The material zinc plated malleable cast iron defines the resistance and the operating limits.

Benefits

• The male thread R 3/4" fits the existing port without an adapter.
• At 50 mm the overall length is defined in the data sheet and can be planned in advance.
• The deflection replaces a bent section of pipe and saves 2 welded or pressed joints.
• The given outlet angle saves 1 pipe bend and keeps the distance to the wall small.

Applications

Changes of direction in the pipe network, connection to vessels and devices, cramped installation situations. The zinc plated malleable cast iron is at home in pipework for water, air and heating systems.
